GRP One Piece Tank - 1000 Litres - 1160 x 1160 x 1130mm

This GRP one-piece tank is manufactured using the highest quality materials and has been manufactured to comply with the requirements of BS EN 13280 (formerly BS 7491 Parts 1, 2 and 3) and is designed to meet all current United Kingdom water regulations where required. The tank is provided in a standard grey colour (BS 00 A 05) but other colours are available upon request.

The tank comes ready to use, can be easily handled and requires no specialist site installation work. The internal gel coat finish on both the tank and lid ensures that harmful bacteria has no place to grow while the resin and gel coats are pigmented throughout to prevent the ingress of light.

The tank lid is secured by bolts and can be removed to allow access to the inside of the tank. The lid provides structural rigidity and it is highly recommended that it not be removed while the tank is full. This tank includes a 600mm x 600mm square manway access on the lid which can be removed when the tank is full, allowing access for inspection or maintenance.

Tank Features

• Manufactured from structural GRP laminate with a high glass content, quality polyester resin and no fillers
• Available as standard or with factory insulation (25mm or 50mm)
• Suitable for internal or external applications – unaffected by sunlight
• All exposed external reinforcements to current European standards
• Smooth internal gel coated surfaces offer excellent resistance to Algae growth
• Weather resistant external finish
• Supplied as standard with a screened vent
• Supplied with a 600mm x 600mm square manway access with cover

Each tank is manufactured in the UK and is factory tested for a minimum of 24 hours to a certified QA procedure. A copy of the test certificate can be supplied if required.

Pre-Insulation

The side and roof panels are manufactured with an integral Polyurethane foam core which is sandwiched in the centre of the plate laminate and the completed laminate and this will provide a minimum thermal conductance of 0.85 or 0.43 w/m2C. The foam used in the insulation is free from both CFC and HCFC and has an ozone depletion factor of 0.

Applications

As standard, this tank is designed for the storage of water, foodstuffs or effluent. If you wish to store a chemical solution in this tank, please send us the MSDS (Material Safety Data Sheet) sheet for the chemical you intend to store, and we can advise if this tank would be suitable or we can provide a quotation for a tank that would be suitable.

Tank Weight Specification

Non Insulated Tank Weight: 56 kg
25mm Insulated Tank Weight: 59 kg
50mm Insulated Tank Weight: 79 kg

Important Delivery Information

The price of this tank includes the shipping to a delivery address in England or Wales only. Please contact us for shipping costs to all other locations including Scotland, Northern Ireland and off-shore islands.

It is the customer’s responsibility to safely unload the tank from the delivery vehicle. Unless agreed prior to delivery, the standard delivery vehicles do not have the facilities to unload your tank.

Please Note: If you add a non-WRAS approved Ball Cock and Float to your order, this will arrive in a separate delivery to the tank and within 2-3 working days.
